BombVault

Your Unraid data, sealed in a vault. Drop a backup. Detonate a restore.

The overview: the status head, what needs you, the protection of each section, the storage locations and the history. The overview: the status head, what needs you, the protection of each section, the storage locations and the history.

BombVault is a self-hosted web app for backup and full disaster recovery on Unraid and other Docker hosts, such as TrueNAS SCALE, ZimaOS or a plain Linux box. It backs up Docker containers, KVM/libvirt VMs, folders, ZFS datasets and the Unraid flash drive. It runs as a single multi-arch Docker container, gives you a web interface in a dark, light or system theme, and handles the whole lifecycle: back up, schedule, verify and restore.

Restores are automatic. On Unraid, containers reappear in the Docker tab exactly as before, and VMs are re-defined in the VM Manager with their disks and UEFI NVRAM reattached. No manual reinstall, no reconfiguration, no drama. On TrueNAS a container restored next to the original runs as a plain Docker container that the Apps screen does not list.

Powered by restic, so every backup is deduplicated, incremental and encrypted by default.

Keep your APP_KEY safe

BombVault derives the restic repository password from a 32-byte secret named APP_KEY. Losing it, together with the recovery kit, makes encrypted backups unrecoverable. Generate one with openssl rand -hex 32 and store it somewhere safe. See Configuration.

What BombVault protects

Every container, VM, folder set, the flash drive, every ZFS dataset and BombVault's own settings is an entry with a page of its own. Entries of one kind form a section, which you switch on under Settings, General.

Section What is saved
Containers Appdata directory plus the container definition (image, env vars, ports, labels, volumes).
VMs VM disk image(s), the XML definition and UEFI NVRAM, backed up over SSH (no libvirt mount).
Flash The whole USB flash (/boot): OS, license, array config, shares, network and plugin config.
Self-backup BombVault's own /config: its settings database, the sign-ins of its storage locations, the libvirt SSH keypair, the key and host pins of the ZFS servers and the certificates.
Folders Any folder on the server as a folder set, each with optional exclude patterns.
ZFS datasets A dataset and every dataset below it, read from one ZFS snapshot and stored like a folder. See ZFS datasets.

Restore is the star

After copying data back from the restic snapshot, BombVault replays the saved container definition against the Docker API, so the container reappears in the Unraid Docker tab as if it had always been there (same image, same settings, same port mappings). VMs get their XML re-defined over SSH and their disks and UEFI NVRAM reattached, even after the VM was deleted.

One window restores every kind. By default it picks Next to the original, which brings the backup back as a copy and leaves the original as it is. Replace original backs up the current state first, so a restore can be undone. A folder or a new ZFS dataset are the other targets.

When a backup stops dependent containers, they come back in the right order: BombVault restarts them in their Compose depends_on order and waits for each to report healthy before starting the ones that depend on it, so nothing races ahead of a database or a gateway that is not up yet. See Restore and Commands and other containers.

How it works

Browser --HTTPS--> BombVault container
                   |- Go binary: JSON API + embedded React UI
                   |- Background worker (per-section scheduler + job executor)
                   |
                   |- /var/run/docker.sock  -> Docker API (container stop/inspect/recreate)
                   |- qemu+ssh://host       -> libvirt / KVM on the HOST over SSH (no mount)
                   |- /mnt/ -> /host/user   -> appdata, VM disks + restic repos (read/write)
                   |- /boot/ -> /host/boot  -> Unraid flash backup (whole USB)
                   |- /config               -> BombVault's own settings + sign-ins (self-backup)
                   '- <repo path>           -> restic repository (local or remote: rclone/s3/rest/sftp)

BombVault uses the Docker socket to stop containers before a backup and to recreate them after a restore. For VMs it runs virsh on the host over SSH (qemu+ssh://) to shut a domain down gracefully or take a live snapshot. It never bind-mounts a libvirt path, so it cannot get in the way of the VM Manager on the host.

BombVault is the orchestration and UI layer, not the storage engine. All actual data movement goes through restic.

Quick start

New here? Head to Getting started to install BombVault and run your first backup, then set up Off-site & recovery. The worked examples walk through the common jobs from start to end, the Settings page lists every tile, and Features is the short catalogue of everything BombVault does.

Each section can copy to several storage locations at once, a paired BombVault can keep your off-site copies in a server that refuses deletes, and the Emergency wizard brings a lost server back from its recovery kit, through your group or with its typed key. To carry your configuration to a new box, use the Export / import settings card. See Off-site & recovery and Configuration.

The Android app puts every server of your group on your phone, with the activity log of all of them on one screen.

The documentation comes in 26 languages and the interface in 42. Pages that have no translation yet show in English.

Words used here

A few words have a fixed meaning in BombVault and in these pages.

Word Meaning
Entry One thing BombVault backs up: a container, a VM, a folder set, the flash drive, a ZFS dataset with the ones below it, or its own settings. Each has a page of its own.
Section All entries of one kind, such as Containers. You switch sections on under Settings, General.
Storage location A place backups go: a folder on this server, a share, a server of your own or a cloud service. See Storage locations.
Local The storage location on this server that holds the sections' folders.
Own folder The repository a section writes its backups to first. It is on this server by default and can lie in a storage location. See A section's own folder.
Copy A backup copied from the own folder to another storage location with restic copy.
Direct repository A repository at an off-site location that entries back up straight to, without a local copy in between. See Direct repositories.
Sign-in The saved key or password for an S3 service or a rest-server. One of them is the default. See Sign-ins.
Placement Which storage locations get an entry's backups, set on the entry or as its section's default. See Placement per entry.
Replica A block-exact copy of a ZFS entry on a second ZFS server, made with zfs send. It stands beside the backup and does not replace it. See Replica.
Role Something one instance of your group does for another: Receiver, Fetcher, ZFS server or Key keeper. See Instances and roles.

Credits

  • VolumeVault by @Darkdragon14 (Apache-2.0) gave BombVault its starting idea: one-click backup and automatic reinstall of Docker containers. BombVault is a separate implementation on Go and restic that carries the idea over to VMs, the flash and more.
  • restic is the fast, secure, deduplicating backup engine BombVault drives.
  • rclone provides the cloud backends.
  • Most glyphs on buttons come from the free Core Solid set by Streamline (CC BY 4.0, source). The others come from Font Awesome Free, Material Design Icons, Simple Icons and Tabler Icons, or were drawn for the project.

License

Copyright (C) 2026 Junker der Provinz. BombVault is free software under the GNU Affero General Public License v3.0 (LICENSE). You may run, study, share and change it. If you distribute it, or run a changed version as a network service, you must publish your source under the same licence and keep the existing copyright and attribution notices.

The name and branding are not licensed. The AGPL covers the source code only: "BombVault", its logo and its branding stay reserved, so a fork has to use a name and branding of its own and may not present itself as BombVault.

Root-equivalent control of the host

Through the Docker socket BombVault can stop, remove and recreate containers and read/write appdata, and for VM backup it logs in to the host over SSH to run virsh. Anyone who can reach its web UI effectively has root on the host. Run BombVault only on a trusted, non-exposed network, and set a login password under Settings, Security. The recovery kit, key deposits, the flash ZIP and exporting a flash or self-backup need one. See Configuration for the full security model.
